Description
The ACE is built around the idea of combining leading user-requested features in a streamlined optic that balances advanced capability with ease-of-use in the field. Designed to feel like a traditional day optic, the ACE is compatible with bolt action or semi-automatic rifles using standard 30 mm mounts and rings.
The Ace H50 acts iRay USA's replacement for the extremely popular but now discontinued Infiray Outdoor Bolt TH50-C V2. The Ace H50 is an improved scope from the TH50 and is impressive in every way.
The combination of an internal USB-C charging battery and a removable 18650 style rechargeable battery allows users to hot-swap batteries in the field to run indefinitely. A 1-3x ocular magnifier provides optical magnification of the 2560x2560 round AMOLED display inside the eyepiece. The Vision+ system pairs this high resolution display with a 15 mK NETD sensor for an incredibly detailed and precise image.
-
Resolution: 640x512
-
Pixel Pitch: 12 micron
-
Refresh Rate: 60hz
-
NETD: <15mk
-
Display: 2560x2560
-
Base Magnification: 3x
-
Digital Zoom: 24x
-
Field of View: 46ft @ 100 yards
-
LRF: No
-
Ballistic Calculator: No
-
*Detection Range (6ft Tall Object): 2,850 yards
-
Battery Type: Internal 18650 and an external 18650 battery
-
Battery Run Time: 3 hrs removable/4 hrs internal (Approximate)
-
Recoil Rating: .300 WIN. Mag./ 7mm Mag.
-
Video/Audio Recording: Yes
-
Streaming App: Yes
-
Single Shot Zero: Yes
-
Color Palettes: White Hot, Black Hot, Red Hot, Color, Crimson, Viridian, Violet
-
Mount Included: Yes – Nocpix 30mm QD Mount
-
Waterproof Rating: IPX67
-
Weight: 2lb 6.6oz
-
Dimensions: 14.37”x3.54”x2.68”
